Location: Philadelphia, Pennsylvania
Philadelphia’s major wastewater treatment facility required screenings collection from multiple bar screens while facing severe space constraints for discharge operations. The engineering solution – dual Pathwinder conveyors with Flex-End discharge systems in a vertically stacked configuration – demonstrates how creative engineering can maximize operational efficiency while minimizing facility footprint in large municipal applications.
Dual Pathwinder conveyors in vertically integrated configuration
Pneumatic actuator systems allowing precise discharge positioning
Multi-sheet engineering drawings (P2-22-1246) with detailed specifications
304 stainless steel construction throughout both conveyor systems
~50% reduction in required facility footprint
Enhanced operational flexibility and redundancy
Optimized capital and operational efficiency
Long-term reliability through proven technology
